ALH
Characteristics / Technical Specications
PUMPS ALHS05 TO ALHS20
Connections SHAFT
B C D H L M N øO R I DIAMETER
FRAME
FASTENINGS
ALHS05
ALHS10
115
(4.5)
226
(8.9)
95
(3.7)
33.5
(1.3)
146
(5.7)
42.5
(1.7)
36.5
(1.4)
ø16 (ø0.6)
81.3
(3.2)
43
(1.7)
18k6 4xM8
ALHS15
ALHS20
193
(7.6)
297
(11.7)
145
(5.7)
52
(2.0)
175
(6.9)
46
(1.8)
35.5
(1.4)
ø20 (ø0.8)
ø25 (ø1.0)
124.8
(4.9)
72
(2.8)
22k6 4xM8
D C
B
HH
RR
C
HH
R R
B
D
M L
I
N
O
L M
O
N
I
2 Patins
3 Patins
2 Patins
3 Patins
2 lobes
3 lobes
2 lobes
3 lobes
PUMPS ALHS15-20
DIMENSIONS
mm (Inch)
