Show Commands
Page 550 7750 SR OS Interface Configuration Guide
ATM PVT Detail Output Fields
Output Port ATM PVT Detail Output — The following table describes port ATM PVT detail output
fields.
Sample Output
A:SR1_5>config>service# show port 1/2/2 atm pvt 0.0 detail
==============================================================================
ATM PVT
==============================================================================
Port Id : 1/2/2 VPI Range : 0.0
Admin State : up Oper state : up
Owner : SAP
Label Description
Port Id
The port ID configured or displayed in the slot/mda/port format.
VPI/VCI
Displays the VPI/VCI values.
Admin State
Displays the administrative state of the interface connection.
Oper State
Indicates the status of the ATM interface.
Encap Type
Indicates the encapsulation type.
Owner
Identifies the system entity that owns a specific ATM connection.
Endpoint Type
Displays the endpoint type.
Cast Type
Indicates the connection topology type.
Ing. Td Idx
Specifies the ATM traffic descriptor profile that applies to the receive
direction of the interface connection.
Egr. Td Idx
Specifies the ATM traffic descriptor profile that applies to the transmit
direction of the interface connection.
Last Changed
Indicates the date and time when the interface connection entered its
current operational state.
Octets
Displays the number of input and output octets.
HEC discarded cells are not included in the input octet numbers.
Cells
Displays the number of input and output cells.
HEC discarded cells are not included in the input cell numbers.
Dropped CLP
Displays the number of times the CLP1 cells have been dropped. CLP1
cells have lower priority than CLP0 cells and are expected to be dis-
carded first in times of congestion.
Dropped Cells
Displays the number of cells dropped by the ATM SAR device.
Tagged Cells
Displays the number of cells that have been demoted from CLP0 to
CLP1.
