Alcatel-Lucent 9500 MPR - Page 101

User Manual
Product information and planning
9500 MPR Rel. 3.1
3DB18809AAAA Issue 1 99/980
3DB23189HCXX 7 GHz 245 7512-7596 ODU 300, 07GHz, T-R 245MHz, 7512-7596MHz, HP, TX
LOW
3DB23189HDXX 7757-7841 ODU 300, 07GHz, T-R 245MHz, 7757-7841MHz, HP, TX
HIGH
3DB23189HEXX 7568-7652 ODU 300, 07GHz, T-R 245MHz, 7568-7652MHz, HP, TX
LOW
3DB23189HFXX 7813-7897 ODU 300, 07GHz, T-R 245MHz, 7813-7897MHz, HP, TX
High
3DB23186HAXX 7 GH 161/
168
7443-7527 ODU 300, 07GHz, T-R 161/168MHz, 7443-7527MHz, HP,
TX LOW
3DB23186HBXX 7611-7695 ODU 300, 07GHz, T-R 161/168MHz, 7611-7695MHz, HP,
TX HIGH
3DB23186HCXX 7499-7583 ODU 300, 07GHz, T-R 161/168MHz, 7499-7583MHz, HP,
TX LOW
3DB23186HDXX 7667-7751 ODU 300, 07GHz, T-R 161/168MHz, 7667-7751MHz, HP,
TX HIGH
3DB23188HAXX 7 GHz 196 7107-7191 ODU 300, 07GHz, T-R 196MHz, 7107-7191MHz, HP, TX
LOW
3DB23188HBXX 7303-7387 ODU 300, 07GHz, T-R 196MHz, 7303-7387MHz, HP, TX
HIGH
3DB23188HCXX 7163-7247 ODU 300, 07GHz, T-R 196MHz, 7163-7247MHz, HP, TX
LOW
3DB23188HDXX 7359-7443 ODU 300, 07GHz, T-R 196MHz, 7359-7443MHz, HP, TX
HIGH
3DB23217HAXX 7 GHz 150 7424-7485 ODU 300, 07GHz, T-R 150MHz, 7424-7485MHz, HP, TX
LOW
3DB23218HAXX 7574-7635 ODU 300, 07GHz, T-R 150MHz, 7574-7635MHz, HP, TX
HIGH
3DB23219HAXX 7470-7530 ODU 300, 07GHz, T-R 150MHz, 7470-7530MHz, HP, TX
LOW
3DB23220HAXX 7620-7680 ODU 300, 07GHz, T-R 150MHz, 7620-7680MHz, HP, TX
HIGH
3DB23221HAXX 7515-7575 ODU 300, 07GHz, T-R 150MHz, 7515-7575MHz, HP, TX
LOW
3DB23222HAXX 7665-7725 ODU 300, 07GHz, T-R 150MHz, 7665-7725MHz, HP, TX
HIGH
APR CODES Freq. TRsp
(MHz)
Frequency
Range
Description
