Alcatel-Lucent 9500 MPR - Page 100

User Manual
Product information and planning
9500 MPR Rel. 3.1
3DB18809AAAA Issue 198/980
3DB23028HAXX 7 GHz 161 7114-7170 ODU 300, 07GHz, T-R 161MHz, 7114-7170MHZ, HP, TX
LOW
3DB23028HFXX 7275-7331 ODU 300, 07GHz, T-R 161MHz, 7275-7331MHZ, HP, TX
HIGH
3DB23028HUXX 7298-7358 ODU 300, 07GHZ, T-R 161MHZ, 7298-7358MHZ, HP, TX
LOW
3DB23028HVXX 7459-7519 ODU 300, 07GHZ, T-R 161MHZ, 7459-7519MHZ, HP, TX
HIGH
3DB23296HAXX 7125-7191 ODU 300, 07GHZ, T-R 161MHZ, 7125-7191MHZ, HP, TX
LOW
3DB23296HBXX 7282-7352 ODU 300, 07GHZ, T-R 161MHZ, 7282-7352MHZ, HP, TX
HIGH
3DB23296HCXX 7209-7275 ODU 300, 07GHZ, T-R 161MHZ, 7209-7275MHZ, HP, TX
LOW
3DB23296HDXX 7367-7436 ODU 300, 07GHZ, T-R 161MHZ, 7367-7436MHZ, HP, TX
HIGH
3DB23298HAXX 7 GHz 154/
161/
168
7480-7554 ODU 300, 07GHz, T-R 154/161/168MHz, 7480-7554MHz,
HP, TX HIGH
3DB23299HAXX 7637-7715 ODU 300, 07GHz, T-R 154/161/168MHz, 7637-7715MHz,
HP, TX HIGH
3DB23026HGXX 7421-7491 ODU 300, 07GHz, T-R 154/161/168MHz, 7421-7491MHz,
HP, TX HIGH
3DB23026HHXX 7581-7652 ODU 300, 07GHz, T-R 154/161/168MHz, 7581-7652MHz,
HP, TX HIGH
3DB23028HEXX 7 GHz 161 7247-7309 ODU 300, 07GHz, T-R 161/168MHz, 7247-7309MHz, HP,
TX LOW
3DB23028HLXX 7408-7470 ODU 300, 07GHz, T-R 161/168MHz, 7408-7470MHz, HP,
TX HIGH
3DB23028HWXX 7333,5-7393 ODU 300, 07GHz, T-R 161/168MHz, 7333,5-7393MHz, HP,
TX LOW
3DB23028HXXX 7494,5-7554 ODU 300, 07GHz, T-R 161/168MHz, 7494,5-7554MHz, HP,
TX HIGH
3DB23189HAXX 7 GHz 245 7428-7512 ODU 300, 07GHz, T-R 245MHz, 7428-7512MHz, HP, TX
LOW
3DB23189HBXX 7673-7757 ODU 300, 07GHz, T-R 245MHz, 7673-7757MHz, HP, TX
HIGH
APR CODES Freq. TRsp
(MHz)
Frequency
Range
Description
