Alcatel-Lucent 9500 MPR - Page 99

User Manual
Product information and planning
9500 MPR Rel. 3.1
3DB18809AAAA Issue 1 97/980
3DB23027HAXX 7 GHz 154 7184-7240 ODU 300, 07GHz, T-R 154MHz, 7184-7240MHz, HP, TX
LOW
3DB23027HBXX 7338-7394 ODU 300, 07GHz, T-R 154MHz, 7338-7394MHz, HP, TX
HIGH
3DB23028HBXX 7 GHz 161 7124-7184 ODU 300, 07GHz, T-R 161MHz, 7124-7184MHz, HP, TX
LOW
3DB23028HGXX 7282-7342 ODU 300, 07GHz, T-R 161MHz, 7282-7342MHz, HP, TX
HIGH
3DB23028HCXX 7170-7230 ODU 300, 07GHz, T-R 161MHz, 7170-7230MHz, HP, TX
LOW
3DB23028HIXX 7331-7391 ODU 300, 07GHz, T-R 161MHz, 7331-7391MHz, HP TX
HIGH
3DB23028HDXX 7208-7268 ODU 300, 07GHz, T-R 161MHz, 7208-7268MHz, HP, TX
LOW
3DB23028HKXX 7366-7426 ODU 300, 07GHz, T-R 161MHz, 7366-7426MHz, HP, TX
HIGH
3DB23028HOXX 7549-7606 ODU 300, 07GHz, T-R 161MHz, 7549-7606MHz, HP, TX
LOW
3DB23028HRXX 7710-7767 ODU 300, 07GHz, T-R 161MHz, 7710-7767MHz, HP, TX
HIGH
3DB23028HPXX 7598-7655 ODU 300, 07GHz, T-R 161MHz, 7598-7655MHz, HP, TX
LOW
3DB23028HSXX 7759-7816 ODU 300, 07GHz, T-R 161MHz, 7759-7816MHz, HP, TX
HIGH
3DB23028HQXX 7633-7690 ODU 300, 07GHz, T-R 161MHz, 7633-7690MHz, HP, TX
LOW
3DB23028HTXX 7794-7851 ODU 300, 07GHz, T-R 161MHz, 7794-7851MHz, HP, TX
HIGH
3DB23026HAXX 7 GHz 154/
161/
168
7424-7488 ODU 300, 07GHz, T-R 154/161/168MHz, 7424-7488MHz,
HP, TX LOW
3DB23026HDXX 7581-7649 ODU 300, 07GHz, T-R 154/161/168MHz, 7581-7649MHz,
HP, TX HIGH
3DB23026HBXX 7480-7544 ODU 300, 07GHz, T-R 154/161/168MHz, 7480-7544MHz,
HP, TX LOW
3DB23026HEXX 7637-7705 ODU 300, 07GHz, T-R 154/161/168MHz, 7637-7705MHz,
HP, TX HIGH
3DB23026HCXX 7512-7568 ODU 300, 07GHz, T-R 154/161/168MHz, 7512-7568MHz,
HP, TX LOW
3DB23026HFXX 7666-7729 ODU 300, 07GHz, T-R 154/161/168MHz, 7666-7729MHz,
HP, TX HIGH
APR CODES Freq. TRsp
(MHz)
Frequency
Range
Description
