IP/V24 WALLBOARD
2 x 16 digits
TECHNICAL
MANUAL
D0503002
23/01/2008
Page 12/18
5.5.3 2x16 Wallboard Connection in Cascade behind Ethernet
RJ45
Ethernet Cable
1 2 3 4
1 2 3 4
1 2 3 4
Wallboard
1
Wallboard 2
Wallboard 8
500m max.
