Alcatel-Lucent OmniPCX Office Installation Manual

Mini-MIX daughter board can be used only in an OmniPCX Office RCE Compact or, in case of migration
from R7.1 or lower, in a Compact Edition 2nd Generation, equipped with a PowerCPU board.
Figure 2.22: Example of Daughter Boards on PowerCPU
2.4.2.14 Provision By Platform
2.4.2.14.1 OmniPCX Office RCE Compact
Board MIX Slot CPU Slot
PowerCPU No Mandatory
MIX x/y/z Yes No
AMIX-1 x/y/z Yes No
2.4.2.14.2 OmniPCX Office RCE Small
Chapter
2
"# !$%  $
2-14
          

Alcatel-Lucent OmniPCX Office Specifications

General

VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Humidity	10% to 90% non-condensing
Type	IP PBX
Maximum Trunks	Up to 60
Voice codecs	G.711, G.729
Network Interfaces	10/100 Ethernet
Weight	Varies depending on the model/configuration
