-> show erp
Legends: WTR - Wait To Restore
MEG - Maintenance Entity Group
Ring Ring Ring Ring Serv WTR Guard MEG Ring Ring
ID Port1 Port2 Status VLAN Timer Timer Level State Node
(min) (csec)
----------+-------+------+---------+-----+-----+-----+-----+-----------+--------
Total number of rings configured = 0
Below is an example (when ERP is configured and running):
-> show erp
Legends: WTR - Wait To Restore
MEG - Maintenance Entity Group
Ring Ring Ring Ring Serv WTR Guard MEG Ring Ring
ID Port1 Port2 Status VLAN Timer Timer Level State Node
(min) (csec)
----------+-------+------+---------+-----+-----+-----+-----+-----------+--------
1 1/1/1 1/1/2 enabled 1001 5 50 1 protection rpl
Total number of rings configured = 1
Below is the command to view the ERP statistics:
-> show erp statistics
Below is an example (default):
-> show erp statistics
Signal_Fail_PDUs No_Request_PDUs No_Req_Block_PDUs Invalid
Ring Port Sent Recv Drop Sent Recv Drop Sent Recv Drop PDU rx
----------+------+------+------+------+------+------+------+------+------+------+-------
Below is an example (when ERP is configured and running):
-> show erp statistics
Signal_Fail_PDUs No_Request_PDUs No_Req_Block_PDUs Invalid
Ring Port Sent Recv Drop Sent Recv Drop Sent Recv Drop PDU rx
----------+------+------+------+------+------+------+------+------+------+------+-------
1 1/1/1 12 9 0 4 54 0 3 1234 0 0
1 1/1/2 0 0 0 4 51 0 0 1234 0 0
Below is the command to view the status of a particular ring:
-> show erp ring <ringid>
Below is an example (when ERP is configured and running):
-> show erp ring 1
Ring Id : 1,
Ring Type : Normal Ring,
Ring Port1 : 1/1/1,
Ring Port2 : 1/1/2,
Ring Status : enabled,
Service VLAN : 1001,
Revertive Mode : enable,
WTR Timer (min) : 5,
