OmniSwitch 6350-P24 OmniSwitch 6350 Chassis and Hardware Components
page 3-12 OmniSwitch 6350 Hardware Users Guide April 2017
OmniSwitch 6350-P24 Rear Panel
Note. The figure shows a pre-production version of the chassis without product, safety, and compliance
information labels. All production versions of the chassis have these labels.
OmniSwitch 6350-P24 Rear Panel
OmniSwitch 6350-P24 Internal AC Power Supply
Item Description
A
Grounding Block
Type LCD8-10A-L grounding lug
B
Power Supply Connector
Internal AC power supply.
P/S Component Description
Model OmniSwitch 6350-P24
Nominal Input Voltage 90-220 VAC
Maximum Output Power 525 W
PoE Power Budget 380 W
Output Voltage 12V DC/54V DC
