General Installation Recommendations Mounting OmniSwitch 6350 Switches
page 4-2 OmniSwitch 6350 Hardware Users Guide April 2017
General Installation Recommendations
Airflow Recommendations
To ensure proper airflow, be sure that your switch is placed in a well-ventilated area and provide minimum
recommended clearance at the front, back and sides of the switch, as shown below. Restricted airflow can
cause your switch to overheat, which can lead to switch failure.
Note. Clearance is not required at the top and bottom of the chassis. Clearance recommendations at the
front and rear of chassis are for access to cabling and components only and are not intended as a specific
airflow requirement.
6 inches minimum at
front of chassis.
2 inches minimum at
left and right sides.
}
}
6 inches minimum at
rear of chassis.
