Port Pinouts
RJ-45 Console Port – Connector Pinout
10/100 Ethernet Port – RJ-45 Pinout (non-PoE)
Gigabit Ethernet Port – RJ-45 Pinout
Pin Number Signals as DTE Console Port
1NC
2NC
3RXD
4Ground
5Ground
6TXD
7NC
8NC
Pin Number Description
1RX+
2RX-
3TX+
4 not used
5 not used
6TX-
7 not used
8 not used
Pin Number Description
1BI_DB+
2BI_DB-
3BI_DA+
4BI_DD+
5BI_DD-
6BI_DA-
7BI_DC+
8BI_DC-
