OmniSwitch 6350-P48 OmniSwitch 6350 Chassis and Hardware Components
page 3-18 OmniSwitch 6350 Hardware Users Guide April 2017
OmniSwitch 6350-P48 Rear Panel
Note. The figure shows a pre-production version of the chassis without product, safety, and compliance
information labels. All production versions of the chassis have these labels.
OmniSwitch 6350-P48 Rear Panel
Item Description
A
Grounding Block
Type LCD8-10A-L grounding lug
B
Power Supply Connector
Internal AC power supply.
