OS6855-24/U24 Power Supplies OmniSwitch 6855 Series Chassis and Hardware Components
page 2-22 OmniSwitch 6855 Series Hardware Users Guide March 2009
PS-126I80AC Power Supply
The PS-126I80AC Power Supply provides full system power for OmniSwitch 6855 Series switches and
can be installed as either a primary or backup system power supply.
80W AC Sytem Power Supply
P/S Component Description
Model PS-126I80AC
Provides System Power For OS6855-24 and OS6855-U24
Input Voltage Range 90 to 265 VAC
Rated Frequency 47 to 63 Hz
Inrush Current < 30A
Maximum Output Power 80 W
Output Voltage 12.0 VDC (typical)
Output Current 6.7 A (maximum)
