AC Power Cords OmniSwitch 6855 Series Chassis and Hardware Components
page 2-36 OmniSwitch 6855 Series Hardware Users Guide March 2009
AC Power Cords
Since the power cord is the switch’s only disconnect device, it should be plugged into an easily accessible
outlet. In the event that your power cord is lost or damaged, refer to the specifications below.
Specifications
The power cord included with this product contains three (3) insulated #18AWG stranded copper wires
and is rated between 85-265 VAC (region dependent), 10 amps with a nominal length of 2 meters. The
female end terminates in an IEC-60320-C15 attachment plug and the male end termination varies depen-
dent upon region, as listed below.
European cords must be Harmonized (HAR) type. Refer to the information below for power plug types by
region:
Supplied 6855 Power Cord Specifications
Power Cord Types User Side Connectors
North America NEMA 5-15-P
United Kingdom / Ireland BS 1363 UK
Europe CEE 7/7
Japan JIS 8303
Australia AS 3112
India BS 546
Italy CIE 23-16
Switzerland / Liechtenstein SEV 1011
Denmark / Greenland SRAF 1962 / DB 16/87
Argentina A-10
Power Cord Notch
Note the power cord notch
designed to match with the
IEC-60320-
C15
