5.3 Installing the roof ue
• Objects must not be installed on the roof within a radius of 200 mm from the flue.
• Lateral distance to the ventilation intake must be at least 300 mm.
• Mark the centre of the point where the flue is to be installed, and drill a 76 mm hole through the roof.
• Pass the flue up through the ceiling. Seal using the collar (Fig. 4, item 1) and roof (Fig. 4, item 2)
use a bodywork sealant and 6 self-tapping screws to secure the flue.
Fire/explosion hazard
The exhaust temperature from the LPG burner can be up to 200 °C.
WARNING
Fig. 4, Installing a roof ue
300 mm
1
2
