AlienTech K-TAG Master - Additional information; Optional accessories

39
Version 1.01
Additional information
Optional accessories
Never use cables or accessories manufactured by companies other than Alientech
Srl.
 BDM Motorola MPC5xx (14KTMA0001)
Accessories available for communication with ECUs of the group BDM Motorola MPC5xx
14AS00T01S
Board to be soldered for Delphi DCI ECUs (4 pin header)
14AS00T02S
Board to be soldered for TRW Truck ECUs
14AS00T03S
Board to be soldered for Siemens and Marelli ECUs (8 pin header)
14AS00T04S
Board to be soldered for Delphi DCM ECUs (4 pin header)
14AM00T00M
Adapter board for positioning frame on Delphi DCI ECUs
14AM00T01M
Adapter board for positioning frame on BOSCH ECUs
14AM00TBAS
Multi-function adapter board for Positioning Frame for 1,27 thread pull-out
tips
14AM00TB01
Pull-out tip for multi-function adapter board for Siemens ECUs
14AM00TB02
Pull-out tip for multi-function adapter board for Marelli ECUs
14AM00TB03
Pull-out tip for multi-function adapter board for BOSCH EDC7 ECUs
14AM00T02M
Adapter board for positioning frame on Delphi DCM ECUs
 JTAG Nexus MPC5xxx (14KTMA0002)
Accessories available for communication with ECUs of the group JTAG Nexus MPC5xxx
14AST00T05S
Board to be soldered for TRW Truck ECUs
14AM00T13M
Adapter board for positioning frame on TRW Truck ECUs
14AM00T05M
Adapter board for positioning frame on Marelli ECUs equipped with MPC5xxx
microprocessor
14AM00T06M
Adapter board for positioning frame on Delphi ECUs equipped with MPC5xxx
microprocessor
14AM00T14M
Adapter board for positioning frame on EFI ECUs equipped with T6
microprocessor
