Replacing the optical drive
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before working inside your computer.
After working inside your computer, follow the instructions
in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
1 Align and snap the optical-drive bezel to the optical drive.
2 Align the screw hole on the optical-drive bracket with the screw hole on
the optical drive.
3 Replace the screw that secures the optical-drive bracket to the optical
drive.
4 Lift the securing tab and slide the optical-drive assembly through the front
of the computer until the securing tab snaps into place.
5 Connect the data and power cables to the optical drive.
Post-requisites
1 Follow the procedure from step 10 to step 11 in "Replacing the power-supply
unit".
2 Replace the left-side cover.
