The Electronic IF-171 Door Handle 11
Insert the handle holder of the mechanical door handle from the other side and screw it along with the
electronic door handle through the door panel. Please use the supplied mounting screws.
Attach the mechanical door handle. Hold the door handle horizontally during this process. Tighten the
rosette towards the left for door handles pointing to the right and guide it over the handle holder; then
let the bayonet lock snap into place.
Tighten the rosette towards the right for door handles pointing to the left.
Screw the locking screw in at the bottom of the rosette. Tighten the screw.
Insert the battery to operate the door handle. Close the housing.
Check the functionality and easy movement of the door handle with the door open. To do this, hold an
authorized credential in front of the reading unit.
When engaged, the catch of the lock should be completely inside the lock housing when the latch is
pressed down.
After holding up an authorized credential for the first time, only the two upper LEDs light up as an
indication.
