Allegion Interflex IF-171 User Manual

Attachment 33
4.3.3 Visual and audible signals for system cards (PegaSys version 2.x)
Note
 System cards are door initialization cards, time initialization cards, blocking list cards and upload
cards.
GREEN --- GREEN
Meaning: Read/- write confirmation for system cards. Data has successfully been read from or written to
the system card.
RED --- RED
Meaning: Read/write error. Failed to read data from or write data to the system card.
Remedy: Hold the system card in front of the NetworkOnCard component a second time.
Booking memory entry: No entry.
4.3.4 Visual/Acoustic Signals with Special Meaning (PegaSys Version 2.0)
RED
Meaning: Electronics were activated but could not read any credential / any card.
Booking memory entry: No entry.
4 × RED
Meaning: Invalid time.
Remedy: Create time initialization card and hold it to the NetworkOnCard component.
5 × RED
Meaning: The NetworkOnCard component has not been initialized.
Remedy: Create door initialization card and hold it to the NetworkOnCard component.
6 × RED
Meaning: The facility card has not yet been held to the NetworkOnCard component.
Remedy: Hold the facility card (again) to the NetworkOnCard component.
4.3.5 Signaling: Data transmission
Data transmission
PegaSys door fitting 2.0, electronic cylinder and locker lock: Orange flashes (
),
followed by another signal.
PegaSys door fitting 2.1: blue (
), followed by another signal.
Meaning: Data transmission. During the data exchange between a system card and another
NetworkOnCard component, the LED flashes. Thereafter, the NetworkOnCard component signals
whether or not the read/write procedure has been successfully completed.
