138 Rockwell Automation Publication 1734-UM013C-EN-P - August 2010
Appendix C Configuration Reference Information
Parameter Name Value Description Default
x Test Output Mode Not Used An external device is not connected. Not Used
Standard The output is connected to a standard device.
Pulse Test A contact output device is connected. Use in combination with
a safety input.
Power Supply The power supply of a Safety Sensor is connected. The voltage
supplied to I/O power (V, G) is output from the test output
terminal.
Muting Lamp Output
(Terminal T1 or T3 only)
An indicator is connected and turned ON to detect broken lines
in an external indicator.
Test Output Fault Action Clear OFF Action to perform when a communication error is detected. Clear OFF
Hold Last Data
Parameter Name Value Description Default
x Output Point Mode Not Used An external output devices is not connected. Not Used
Safety When the output is ON, the test pulse is not output (remains ON).
Safety Pulse Test Using this function, short-circuits between output signal lines and the
power supply (positive side) and short-circuits between output signal
lines can be detected.
x Output Point Operation
Type
Single Channel Use as single channel. Dual-channel
Dual-channel Use as dual-channel. When both channels are normal, outputs can be
turned ON.
x Safety Output Error
Latch Time
0…65,530 ms
(in increments of 10 ms)
Safety output errors are latched for this time. 1000 ms
Parameter Name Value Description Default
Test Output Idle State
(1)
Clear OFF or Keep Output
Data
Definition of output data is in idle state. Clear OFF
(1) Set only through explicit messaging. Refer to for Appendix A more information.
