Rockwell Automation Publication 1734-UM013C-EN-P - August 2010 95
Chapter
7
Configure the Module for a
SmartGuard Controller
Introduction
This chapter provides information about how to configure a SmartGuard
controller and POINT Guard I/O modules by using USB (Universal Serial Bus)
connectivity. Refer to the corresponding RSNetWorx for DeviceNet software
help files for network-configurator operating procedures.
Before You Begin
Be sure you have these required items:
• RSNetWorx for DeviceNet software, version 9.0 or later
• RSLinx software, version 2.51 or later
• SmartGuard USB driver
The SmartGuard USB driver should already be in your RSLinx software. If
it is not, load the driver onto your computer, noting the folder location as
you need to browse to it later.
• Personal computer with a Microsoft Windows 2000, MicrosoftWindows
2000 Terminal Server, or MicrosoftWindows XP operating system
• 1734-PDN adapter
• 1734-IB8S and/or 1734-OB8S EDS files
Topic Page
Introduction 95
Before You Begin 95
Use Help 96
Work with RSNetWorx for DeviceNet Software 96
Set Up the Safety Configuration 98
Set Up the Input and Output Connections of the SmartGuard
Controller
104
Save and Download Module Configuration 109
To download the appropriate EDS file, visit the EDS Hardware
and Installation website at http://
www.rockwellautomation.com/resources/eds/.
The EDS file for the 1734-IB8S module is 0010023000F0100.
The EDS file for the 1734-OB8S module is 001002300100100.
