Rockwell Automation Publication 1734-UM013C-EN-P - August 2010 65
Chapter
6
Configure the Module in a
GuardLogix Controller
Introduction
When using a GuardLogix controller, configure the POINT Guard I/O
modules with RSLogix 5000 software, version 17, by using the appropriate
add-on profile.
Topic Page
Introduction 65
Use Help 66
Add Modules to the I/O Configuration Tree 66
Add and Configure the Ethernet Bridge Module 66
Add and Configure the 1734-AENT Adapter 69
Add and Configure Safety Input Modules 72
Add and Configure Safety Output Modules 78
Values and States of Tags 85
Configure the Safety Tab 86
Configuration Ownership 88
Configuration Signature 88
Configure the Input Configuration Tab 89
Configure the Input Configuration Tab 89
Configure the Test Output Tab 92
Configure the Output Configuration Tab 93
Saving and Downloading Module Configuration 94
You must configure each point that is to be used as a safety
input or output. By default, all safety input and output points
are disabled.
To download an add-on profile, visit the RSLogix 5000 My
Support website at http://support.rockwellautomation.com/
ControlFlash/LogixProfiler.asp.
