Rockwell Automation Publication 1734-UM013C-EN-P - August 2010 17
POINT Guard I/O Overview Chapter 1
Figure 2 - POINT Guard I/O Modules in DeviceNet Safety Architectures
5
6
1
3
2
4
Item Description
1 ControlLogix controller
2 POINT I/O and POINTGuard I/O
3 Guard I/O
4SmartGuard
5 Safety communication
6 Standard communication
