20 Rockwell Automation Publication 1734-UM013C-EN-P - August 2010
Chapter 2 Safety Functions
Figure 3 - Safety Status
The module is designed for use in applications where the safety state is the
off state.
Item Description
1 Inputs to Network Off
2 Safety status
3 Input
4 Output off
5Networks
4
3
15
2
44076
