244 Rockwell Automation Publication 1756-UM058G-EN-P - November 2012
Appendix G 1492 IFMs for Digital I/O Modules
1756-OA16 1492-IFM20F Feed-through Standard 1492-CABLExX
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20D120N Status-indicating Narrow standard with 120V AC status indicators
1492-IFM20D120-2 120V AC/DC status indicators and extra terminals for outputs
1492-IFM20F-F2 Fusible Extra terminals for outputs
1492-IFM20F-F120-2 Extra terminals with 120V AC blown fuse indicators for outputs
1492-IFM20F-F240-2 Extra terminals with 240V AC blown fuse indicators for outputs
1492-XIM20120-8R Relay Master 20-pin master with eight, 24V DC relays
(3)
1492-XIM20120-16R 20-pin master with sixteen, 120V AC relays
1492-XIM20120-16RF 20-pin master with sixteen, 120V AC relays with fusing
1492-XIM120-8R Relay Expander Expander with eight, 120V AC relays
(4)
1492-XIMF-F120-2 Fusible Expander Expander with eight, 120V channels with blown fuse indicators
(4)
1492-XIMF-2 Feed-through Expander Expander with eight feed-through channels
(4)
1756-OA16I 1492-IFM40F Feed-through Standard 1492-CABLExY
(x=cable length)
1492-IFM40DS120-4 Status-indicating Isolated with 120V AC status indicators and four terminals per output
1492-IFM40-FS-2 Fusible Isolated with extra terminals for outputs
1492-IFM40-FS-4 Isolated 240V AC/DC with four terminals per output
1492-IFM40F-FS120-2 Isolated with extra terminals and 120V AC/DC blown fuse indicators
1492-IFM40F-FS120-4 Isolated with 120V AC/DC blown fuse indicators and four terminals per output
1492-IFM40F-FS240-4 Isolated with 240V AC/DC blown fuse indicators and four terminals per output
1756-OB8 1492-IFM20F Feed-through Standard 1492-CABLExU
(x=cable length)
1492-IFM20FN Narrow standard
1492-IMF20F-2 Extra terminals
1492-IFM20DS24-4 Status-indicating Isolated with 24/48V AC/DC status indicators and four terminals per output 1492-CABLExW
(x=cable length)
1492-IFM20F-FS-2 Fusible Isolated 120V AC/DC with extra terminals for outputs
1492-IFM20F-FS24-2 Isolated with extra terminals per output and 24V AC/DC blown fuse indicators
1756-OB8EI 1492-IFM40F Feed-through Standard 1492-CABLExY
(x=cable length)
1492-IFM40DS24-4 Status-indicating Isolated with 24/48V AC/DC status indicators and four terminals per output
1492-IFM40F-FS-2 Fusible Isolated with extra terminals for 120V AC/DC outputs
1492-IFM40F-FS24-2 Isolated with extra terminals and 24V AC/DC blown fuse indicators for outputs
1492-IFM40F-FS24-4 Isolated with 24V AC/DC blown fuse indicators and four terminals per output
1492-IFM40F-FS-4 Isolated 240V AC/DC with four terminals per output
1756-OB8I N/A
Table 65 - IFMs and Prewired Cables (continued)
I/O Cat. No. IFM Cat. No. IFM Type IFM Description Prewired Cable
