Rockwell Automation Publication 1756-UM058G-EN-P - November 2012 245
1492 IFMs for Digital I/O Modules Appendix G
1756-OB16D 1492-IFM40F Feed-through Standard 1492-CABLExY
(x=cable length)
1492-IFM40F-2 Extra terminals
1492-IFM40DS24-4 Status-indicating Isolated with 24/48V AC/DC status indicators and four terminals per output
(5)
1492-IFM40F-F24D-2 Fusible Fused with 24V DC blown fuse low leakage status indicator circuit with four isolated
groups and four terminals per output
1492-IFM40F-FS-2 Isolated with extra terminals for 120V AC/DC outputs
1492-IFM40F-FS24-2 Isolated with extra terminals and 24V AC/DC blown fuse indicators for outputs
(6)
1492-IFM40F-FS24-4 Isolated with extra terminals and 24V AC/DC blown fuse indicators and four terminals
per output
(6)
1492-IFM40F-FS-4 Isolated 240V AC/DC with four terminals per output
1756-OB16E 1492-IFM20F Feed-through Standard 1492-CABLExX
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20D24 Status-indicating Standard with 24V AC/DC status indicators
1492-IFM20D24N Narrow standard with 24V AC/DC status indicators
1492-IFM20D24-2 24V AC/DC status indicators and extra terminals for outputs
1492-IFM20F-F2 Fusible 120V AC/DC with extra terminals for outputs
1492-IFM20F-F24-2 Extra terminals with 24V AC/DC blown fuse indicators
1492-XIM2024-8R Relay Master 20-pin master with eight, 24V DC relays
(7)
1492-XIM2024-16R 20-pin master with sixteen, 24V DC relays
1492-XIM2024-16RF 20-pin master with sixteen, 24V DC relays with fusing
1492-XIM24-8R Relay Expander Expander with eight, 24V DC relays
(4)
1492-XIMF-F24-2 Fusible Expander Expander with eight, 24V channels with blown fuse indicators
(4)
1492-XIMF-2 Feed-through Expander Expander with eight feed-through channels
(4)
1756-OB16I
1756-OB16IEF
1756-OB16IEFS
1492-IFM40F Feed-through Standard 1492-CABLExY
(x=cable length)
1492-IFM40DS24-4 Status-indicating Isolated with 24/48V AC/DC status indicators and four terminals per output
1492-IFM40F-FS-2 Fusible Isolated with extra terminals for 120V AC/DC outputs
(8)
1492-IFM40F-FS24-2 Isolated with extra terminals and 24V AC/DC blown fuse indicators for outputs
(8)
1492-IMF40F-FS24-4 Isolated with 24V AC/DC blown fuse indicators and four terminals per output
(8)
1492-IFM40F-FS-4 Isolated with 240V AC/DC and four terminals per output
(8)
1756-OB16IS 1492-IFM40F Feed-through Standard 1492-CABLExY
(x=cable length)
1492-IFM40DS24-4 Status-indicating Isolated with 24/48V AC/DC status indicators and four terminals per output
1492-IFM40F-FS-2 Fusible Isolated with extra terminals for 120V AC/DC outputs
(8)
1492-IFM40F-FS24-2 Isolated with extra terminals and 24V AC/DC blown fuse indicators for outputs
(8)
1492-IMF40F-FS24-4 Isolated with 24V AC/DC blown fuse indicators and four terminals per output
(8)
1492-IFM40F-FS-4 Isolated with 240V AC/DC and four terminals per output
(8)
Table 65 - IFMs and Prewired Cables (continued)
I/O Cat. No. IFM Cat. No. IFM Type IFM Description Prewired Cable
