246 Rockwell Automation Publication 1756-UM058G-EN-P - November 2012
Appendix G 1492 IFMs for Digital I/O Modules
1756-OB32 1492-IFM40F Feed-through Standard 1492-CABLExZ
(x=cable length)
1492-IFM40F-2 Extra terminals
1492-IFM40D24 Status-indicating Standard with 24V AC/DC status indicators
1492-IFM40D24-2 24V AC/DC status indicators and extra terminals for outputs
1492-IFM40F-F2 Fusible 120V AC/DC with extra terminals for outputs
1492-IFM40F-F24-2 Extra terminals with 24V AC/DC blown fuse indicators for outputs
1492-XIM4024-8R Relay Master 40-pin master with eight, 24V DC relays
1492-XIM4024-16R 40-pin master with sixteen, 24V DC relays
1492-XIM4024-16RF 40-pin master with sixteen, 24V DC relays with fusing
1492-XIM24-8R Relay Expander Expander with eight, 24V DC relays
(4)
1492-XIMF-F24-2 Fusible Expander Eight-channel expander with 24V AC blown fuse indicators
(4)
1492-XIM24-16RF Expander with sixteen, 24V DC relays with fusing
(9)
1492-XIMF-2 Feed-through Expander Expander with eight feed-through channels
(4)
1756-OC8 1492-IFM20F Feed-through Standard 1492-CABLExU
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20DS24-4 Status-indicating Isolated with 24/48V AC/DC status indicators and four terminals per output 1492-CABLExW
(x=cable length)
1492-IFM20F-FS2 Fusible Isolated 120V AC/DC with extra terminals for outputs
1492-IFM20F-FS24-2 Isolated with extra terminals per output and 24V AC/DC blown fuse indicators
1756-OG16 N/A
1756-OH8I 1492-IFM40F Feed-through Standard 1492-CABLExY
(x=cable length)
1492-IFM40F-FS-2 Fusible Isolated with extra terminals for 120V AC/DC outputs
1492-IFM40F-FS120-2 Isolated with extra terminals and 120V AC/DC blown fuse indicators
1756-ON8 1492-IFM20F Feed-through Standard 1492-CABLExU
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20DS24-4 Status-indicating Isolated with 24/48V AC/DC status indicators and four terminals per output 1492-CABLExW
(x=cable length)
1492-IFM20F-FS2 Fusible Isolated 120V AC/DC with extra terminals for output
1492-IFM20F-FS24-2 Isolated with extra terminals per output and 24V AC/DC blown fuse indicators
1756-OV16E 1492-IFM20F Feed-through Standard 1492-CABLExX
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20D24 Status-indicating Standard with 24V AC/DC status indicators
1492-IFM20D24-2 24V AC/DC status indicators and extra terminals for outputs
1492-IFM20F-F2 Fusible 120V AC/DC with extra terminals for outputs
1492-IFM20F-F24-2 Extra terminals with 24V AC/DC blown fuse indicators
Table 65 - IFMs and Prewired Cables (continued)
I/O Cat. No. IFM Cat. No. IFM Type IFM Description Prewired Cable
