Allen-Bradley 1761-NET-AIC User Manual

Publication 1761-UM004B-EN-P - June 2006
Network Connections 25
Networked Operator-interface Device and MicroLogix Controller
Networked Operator-interface Device and MicroLogix Controller
1761-CBL-AM00 or
1761-CBL-HM02 Cable
Connection from NULL Modem
Adapter
PanelView 550 Operator Interface
RS-232 Port
NULL Modem
Adapter
SLC DH-485 Network
PC
1761-CBL-AP00 or
1761-CBL-PM02 Cable
1747-CP3 or
1761-CBL-AC00 Cable
24V dc
(user supplied)
SLC 5/03 Processor
1747-AIC
Isolated Link Coupler
24V dc
(user supplied)
24V dc
(Not needed in this
configuration since
the MicroLogix
1000 provides
power to the AIC+
via port 2.)
MicroLogix 1000 Processor (series C or later)
1761-CBL-AP00 or
1761-CBL-PM02 Cable
1747-CP3 or
1761-CBL-AC00 Cable
AIC+ Converter
AIC+ Converter
AIC+ Converter
1
1
2
2
2
3
3
3
