28 Network Connections
DF1 Master-slave Network with Modem
DF1 Master-slave Network with Modem
Use this diagram for user-mode ASCII as well as DF1 master-slave
protocol.
See Specifications for more information on hardware handshaking and
communication protocols.
DF1
Slave
DF1
Slave
DF1
Master
AIC+ Converter
1761-CBL-AP00 or
1761-CBL-PM02 Cable
SLC 5/03 Processor
CH0
Radio Modem
or Lease Line
Straight 9...25 Pin Cable
1761-CBL-AP00 or
1761-CBL-PM02 Cable
AIC+ Converter
1761-CBL-AP00 or
1761-CBL-PM02 Cable
CH0
Straight
9...25
Pin Cable
DF1
Slave
CH0
1747-CP3 or
1761-CBL-AC00 Cable
1761-CBL-AP00 or
1761-CBL-PM02 Cable
CH0
1747-CP3 or
1761-CBL-AC00 Cable
SLC 5/03 processor
SLC 5/03 Processor
SLC 5/03 Processor
AIC+ Converter
1
AIC+ Converter
3
3
3
2
1
2
3
1
2
1
2
Radio Modem
or Lease Line
