Publication 1761-UM004B-EN-P - June 2006
Network Connections 29
Avoid Incorrect Connections
Incorrect Connections
IMPORTANT
In this configuration, the cable will fit but not function properly.
DH-485
Network
1761-CBL-AS09 or
1761-CBL-AS03 Cable
1747-AIC Isolated
Link Coupler
DH-485
Network
1761-CBL-AS09 or
1761-CBL-AS03 Cable
SLC 5/03 Processor
1747-AIC Isolated
Link Coupler
AIC+ Converter
3
