26 Network Connections
Networks Using Ganged Converters
Networks Using Ganged Converters
1761-CBL-AS09 or
1761-CBL-AS03 Cable
24V dc
(user supplied)
1747-CP3 or 1761-CBL-AC00 Cable
PanelView Interface
PC
RJ45 Port
1761-CBL-AM00 or
1761-CBL-HM02 Cable
1761-CBL-AS09 or
1761-CBL-AS03 Cable
24V dc power
1747-CP3 or
1761-CBL-AC00 Cable
PC
RJ45 Port
1761-CBL-AM00 or
1761-CBL-HM02 Cable
DH-485
Network
DH-485
Network
24V dc
(user supplied)
DH-485 Network with PanelView Interface
SLC 500 Fixed Controller
AIC+ Converter
3
1
2
AIC+ Converter
1
2
2
AIC+ Converter
3
3
AIC+ Converter
2
3
