Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 143
Module Tag Definitions Appendix B
Chxx.SensorType SINT RTD Mode:
• 0 =no linearization, Ω
• 1 = 100 Ω Platinum 385
• 2 = 200 Ω Platinum 385
• 3 = 500 Ω Platinum 385
• 4 = 1000 Ω Platinum 385
• 5 = 100 Ω Platinum 3916
• 6 = 200 Ω Platinum 3916
• 7 = 500 Ω Platinum 3916
• 8 = 1000 Ω Platinum 3916
• 9 = 10 Ω Copper 427
• 10 = 120 Ω Nickel 672
• 11 = 100 Ω Nickel 618
• 12 = 120 Ω Nickel 618
• 13 = 200 Ω Nickel 618
• 14 = 500 Ω Nickel 618
Thermocouple Mode:
• 0 = mV
• 1 = B
• 2 = C
• 3 = E
• 4 = J
• 5 = K
• 6 = N
• 7 = R
• 8 = S
• 9 = T
• 10 = TXK/XK (L)
Chxx.NotchFilter SINT Notch Filter removes line noise for the channel. • 0 = 10 Hz (simultaneous 50/60Hz
rejection)
• 1 = 50 Hz
• 2 = 60 Hz
• 3 = 100 Hz
• 4 = 200 Hz
• 5 = 500 Hz
• 6 = 1,000 Hz
• 7 = 2,500 Hz
• 8 = 5,000 Hz
• 9 = 10,000 Hz
• 10 = 15,625 Hz
• 11 = 25,000 Hz
• 12 = 31,250 Hz
• 13 = 5 Hz
• 14 = 62,500 Hz
• 15 = 15 Hz
• 16 = 20 Hz
Chxx.AlarmDisable BOOL Disables all alarms on the channel.
IMPORTANT: Consider the following:
• When if you change this tag to 0, that is, so alarms are not disabled, you
must also enable the individual alarms for them to work.
For example, if you want to use the Low Low alarm for a channel, you
must set the Chxx.AlarmDisable to 0 and set the Chxx.LLAlarmEn output
tag to 1 so the alarm is enabled.
This applies to all alarms on the module.
• Conversely, if you set this tag to 1, alarms are disabled regardless of the
setting on the alarm enable tag for any alarm.
• 0 = Alarms are enabled
• 1 = Alarms are disabled (default)
Table 33 - 5069-IY4 Module - Configuration Tags
Name Size Definition Valid Values
To Next Page
