Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 109
Chapter 7
Calibrate the Module
The 5069 Compact I/O™ analog I/O modules are calibrated during the
manufacturing process. Each module’s accuracy remains high throughout its
lifespan. You are not required to calibrate the module.
You can calibrate on a per channel basis or in groups.
Before You Begin
Consider the following before you begin:
•
Controller State During Calibration
•
Calibration Impacts Data Quality on Entire Input Module Group
Topic Page
Before You Begin 109
Difference Between Calibrating an Input Module and an
Output Module
111
Calibrate the Input Modules 112
Calibrate the Output Modules 118
IMPORTANT
This chapter describes a few example module calibration scenarios. It does not
cover how to calibrate every 5069 Compact I/O analog I/O module in all of the
operating modes that the module supports.
