Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 151
Module Tag Definitions Appendix B
Output Tags
Table 35 describes the 5069-IY4 module output tags.
Table 35 - 5069-IY4 Module - Output Tags
Name Size Definition Valid Values
Chxx.LLAlarmEn BOOL Enables the Low Low alarm.
IMPORTANT: To use this alarm, you must not only set the tag to 1. You must
also make sure the Chxx.AlarmDisable configuration tag for the same
channel is set to 0.
If the Chxx.AlarmDisable configuration tag is set to 1, that is, alarms are
disabled, this alarm does not work regardless of the tag value.
• 0 = Alarm is disabled
• 1 = Alarm is enabled
Chxx.LAlarmEn BOOL Enables the Low alarm.
IMPORTANT: To use this alarm, you must not only set the tag to 1. You must
also make sure the Chxx.AlarmDisable configuration tag for the same
channel is set to 0.
If the Chxx.AlarmDisable configuration tag is set to 1, that is, alarms are
disabled, this alarm does not work regardless of the tag value.
• 0 = Alarm is disabled
• 1 = Alarm is enabled
Chxx.HAlarmEn BOOL Enables the High alarm.
IMPORTANT: To use this alarm, you must not only set the tag to 1. You must
also make sure the Chxx.AlarmDisable configuration tag for the same
channel is set to 0.
If the Chxx.AlarmDisable configuration tag is set to 1, that is, alarms are
disabled, this alarm does not work regardless of the tag value.
• 0 = Alarm is disabled
• 1 = Alarm is enabled
Chxx.HHAlarmEn BOOL Enables the High High alarm.
IMPORTANT: To use this alarm, you must not only set the tag to 1. You must
also make sure the Chxx.AlarmDisable configuration tag for the same
channel is set to 0.
If the Chxx.AlarmDisable configuration tag is set to 1, that is, alarms are
disabled, this alarm does not work regardless of the tag value.
• 0 = Alarm is disabled
• 1 = Alarm is enabled
Chxx.RateAlarmEn BOOL Enables the Rate alarm.
IMPORTANT: To use this alarm, you must not only set the tag to 1. You must
also make sure the Chxx.AlarmDisable configuration tag for the same
channel is set to 0.
If the Chxx.AlarmDisable configuration tag is set to 1, that is, alarms are
disabled, this alarm does not work regardless of the tag value.
• 0 = Alarm is disabled
• 1 = Alarm is enabled
Chxx.LLAlarmUnlatch BOOL Unlatches a latched Low Low Alarm at the first instance of the bit
transitioning from 0 to 1.
• 0 = Low Low Alarm remains
latched
• 1 = Low Low Alarm unlatches
Chxx.LAlarmUnlatch BOOL Unlatches a latched Low Alarm at the first instance of the bit transitioning
from 0 to 1.
• 0 = Low Alarm remains latched
• 1 = Low Alarm unlatches
Chxx.HAlarmUnlatch BOOL Unlatches a latched High Alarm at the first instance of the bit transitioning
from 0 to 1.
• 0 = High Alarm remains latched
• 1 = High Alarm unlatches
Chxx.HHAlarmUnlatch BOOL Unlatches a set High High Alarm at the first instance of the bit transitioning
from 0 to 1.
• 0 = High High Alarm remains
latched
• 1 = High High Alarm unlatches
