Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 13
Analog I/O Module Operation in a Logix5000 Control System Chapter 1
5069 Compact I/O System Power
The 5069-AEN2TR EtherNet/IP adapter provides system-side and field-side
power to a 5069 Compact I/O system.
• System-side power that powers the 5069 Compact I/O system and lets
modules transfer data and execute logic.
• Field-side power that powers field-side devices that are connected to some
5069 Compact I/O modules.
For more information on how to power a 5069 Compact I/O system, see the
EtherNet/IP Communication Modules in 5000 Series Systems User Manual,
publication
ENET-UM004
Configure a 5069 Compact
I/O System
You must create a Logix Designer application project for the Logix5000
controller that owns the 5069 Compact I/O analog I/O module. The project
includes module configuration data for the 5069 Compact I/O analog I/O
modules.
The Logix Designer application transfers the project to the owner-controller
during the program download. Data is then transferred to the 5069 Compact
I/O analog I/O modules over the EtherNet/IP network.
The 5069 Compact I/O analog I/O modules can operate immediately after
receiving the configuration data.
Connections
During module configuration, you must define the module. Among the Module
Definition parameters, you must choose a connection type for the module. A
connection is a real-time data transfer link between the owner-controller and the
module that occupies the slot that the configuration references.
When you download module configuration to a controller, the controller
attempts to establish a connection to each module in the configuration.
