Module Tag Definitions Appendix B
5069-OF4, 5069-OF8
Module Tags
This section describes the tags associated with the 5069-OF4 and 5069-OF8
modules. The tags are the same for each module with the only difference being
that one module supports four output channels and one module supports eight
output channels.
Configuration Tags
Table 36 describes the 5069-OF4, 5069-OF8 module configuration tags.
Table 36 - 5069-OF4, 5069-OF8 Module - Configuration Tags
Name Size Definition Valid Values
Chxx.Range SINT Channel’s operating range • 0 = -10…10V
• 1 = 0…5V
• 2 = 0…10V
• 4 = 0…20 mA
• 5 = 4…20 mA
Chxx.AlarmDisable BOOL Disables all alarms on the channel. • 0 = Alarms are enabled
• 1 = Alarms are disabled (default)
Chxx.LimitAlarmLatchEn BOOL Configures Limit alarms to latch until they are explicitly unlatched. • 0 = Latching disabled (default)
• 1 = Latching enabled
Chxx.RampAlarmLatchEn BOOL Latches Ramp alarm when set so that does not clear until explicitly
unlatched.
• 0 = Latching disabled (default)
• 1 = Latching enabled
Chxx.NoLoadEn BOOL Enable the input No Load diagnostic • 0 = Disabled (default)
• 1 = Enabled
Chxx.Disable BOOL Disables the channel. • 0 = Channel is enabled (default)
• 1 = Channel is disabled
Chxx.FaultMode BOOL Determines output action when a connection fault occurs.
At the fault occurrence, the output holds its last state or transitions to the
value set in the Fault Value parameter.
The channel continues the Fault Mode for the length of time set in the Fault
Value State Duration parameter.
• 0 = Transition to user-defined value
• 1 = Hold Last State (default)
Chxx.ProgMode BOOL Determines output action when the controller transitions to Program mode
or the connection to the module is inhibited.
At the transition to Program mode, the output holds its last state or
transitions to the value set in the Program Value parameter.
• 0 = Transition to user-defined value
• 1 = Hold Last State (default)
Chxx.ProgramToFaultEn BOOL Determines channel action if a connection faults while the module is in a
safe state for Program mode.
The channel can remain in the safe state for Program mode or transition to a
safe state for Fault mode.
If the channel remains in safe state for Program mode, the Final Fault State
parameter is ignored.
• 0 = Remains in the Program state
• 1 = Transitions to the safe state for the
Fault mode
Chxx.RampInRun BOOL Enables Output Ramping when the module is in Run mode.
Output changes during Run mode are limited to the Maximum Ramp Rate
value.
• 0 = Ramping disabled (default)
• 1 = Ramping enabled in Run mode
To Next Page
