Troubleshoot Your Module Appendix A
5069 Compact I/O Analog
Output Modules
Status Indicators
Figure 8 shows the status indicators on the 5069 Compact I/O analog output
modules.
Figure 8 - 5069 Compact I/O Analog Output Module Status Indicators
Output 0 +
Output 0 -
Output 1 +
Output 1 -
Output 2 +
Output 2 -
Output 3 +
Output 3 -
Shield
Shield
5069-OF4
Module Status Indicator
I/O Status Indicators
Shield
Shield
5069-OF8
Module Status Indicator
I/O Status Indicators
Output 0 +
Output 0 -
Output 1 +
Output 1 -
Output 2 +
Output 2 -
Output 3 +
Output 3 -
Output 4 +
Output 4 -
Output 5 +
Output 5 -
Output 6 +
Output 6 -
Output 7 +
Output 7 -
