Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 73
Chapter 5
Current/Voltage Analog Output Module
Features (5069-OF4, 5069-OF8)
The 5069-OF4 and 5069-OF8 output modules have four and eight non-isolated
channels, respectively. Each channel supports connection to the following
output types:
• Current
• Vo l t age
Topic Page
Module Features 74
Fault and Status Reporting 82
IMPORTANT
Remember the following:
• This module also has features that apply to all 5069 Compact I/O™ analog I/
O modules that are described in Chapter 2,
Common Analog I/O Module
Features on page 25.
• You can configure the features that are described in this chapter with the
Logix Designer application.
For more information on how to configure the module, see Chapter 6,
Configure the Module on page 83.
