Module Tag Definitions Appendix B
Chxx.ShortCircuit BOOL A Short Circuit or Overcurrent condition exists.
This condition is detected only when the channel is used in voltage mode.
• 0 = No Short Circuit or
Overcurrent condition exists
• 1 = Short Circuit or Overcurrent
condition exists
Chxx.OverTemperature BOOL Module is higher temperature than its operating limits.
• If this tag is set to 1 but a fault does not exist on the channel, this tag is
only an indication of operating conditions but the channel is functioning.
• If this tag is set to 1 and a fault exists on the channel, the channel is not
functioning.
• 0 = Module temperature is not
over the operating limits
• 1 = Module temperature is over
the operating limits
Chxx.FieldPowerOff BOOL Field power is not present at the channel.
Field power is provided through the SA power connector on the 5069-
AEN2TR EtherNet/IP adapter or a 5069-FPD field potential distributor.
• 0 = Field Power is present
• 1 = Field Power is not present
Chxx.InHold BOOL Indicates that the channel is currently holding until the received data value
is within 0.1% range full scale of the current data value.
• 0 = Channel is not holding
• 1 = Channel is holding
Chxx.NotANumber BOOL Indicates that the last value received for the channel output data value was
not a number.
• 0 = Last channel data received
was a number
• 1 = Last channel data received
was not a number
Chxx.Underrange BOOL Indicates the channel data is beneath the underrange threshold for this
channel.
For example, when the channel operates in the 4…20 mA output range,
the underrange threshold on the channel is
< 3.6 mA. If the output signal is
0 mA, this tag is set to 1.
• 0 = Channel data is not beneath
the underrange threshold
• 1 = Channel data is beneath the
underrange threshold
Chxx.Overrange BOOL Indicates the channel data is above the overrange threshold for this channel.
For example, when the channel operates in the 4…20 mA output range,
the overrange threshold on the channel is > 21.0 mA. If the output signal is
21 mA, this tag is set to 1.
• 0 = Channel data is not above
the overrange threshold
• 1 = Channel data is above the
overrange threshold
Chxx.LLimitAlarm BOOL Triggered when the requested output value is below the configured Low
Limit value. It remains set until the requested output is above the Low Limit.
If the Chxx.AlarmDisable tag is set to 1, that is, the output signal is still
clamped at the Low Limit value. But the Low Limit alarm is not triggered.
• 0 = Alarm is not triggered
• 1 = Alarm is triggered
Chxx.HLimitAlarm BOOL Triggered when the requested output value is above the configured High
Limit value. It remains set until the requested output is below the High
Limit.
If the Chxx.AlarmDisable tag is set to 1, that is, the output signal is still
clamped at the High Limit value. But the High Limit alarm is not triggered.
• 0 = Alarm is not triggered
• 1 = Alarm is triggered
Chxx.RampAlarm BOOL Indicates that the analog output has been commanded to change value in a
way such that the Maximum Ramp Rate is exceeded
• 0 = Alarm is not triggered
• 1 = Alarm is triggered
Chxx.CalFault BOOL Indicates the last attempted Calibration for this channel failed.
This tag is cleared, that is, set to 0, when power is cycled to the module.
• 0 = Calibration did not fail
• 1 = Calibration failed
Chxx.Calibrating BOOL Indicates the channel is currently being calibrated. • 0 = Channel is not being
calibrated
• 1 = Channel is being calibrated
Table 37 - 5069-OF4, 5069-OF8 Modules - Input Tags
