Allen-Bradley 6181X-NPXPDC User Manual

Rockwell Automation Publication 6181X-UM001C-EN-P - July 2015 23
Installation Chapter 2
Computer Dimensions
Review computer dimensions to estimate the clearance necessary for computer
installation.
Figure 3 - Non-display Computers
Figure 4 - Integrated Display Computers
1.6
(0.06)
190.5
(7.5)
83.4
(3.28)
57.5
(2.26)
335.3 (13.2)
320.2 (12.61)
238.2
(9.37)
16.4
(0.65)
16.4
(0.65)
87.1
(3.43)
87.1
(3.43)
87.1
(3.43)
251
(9.88)
Dimensions are in mm (in.)
115 (4.53)
349 (13.74)
101.3 (4)
75.4 (2.97)
14.5 (0.57)
320 (12.6)
251
(9.88)
279
(10.98)
115 (4.53)
Dimensions are in mm (in.)

Allen-Bradley 6181X-NPXPDC Specifications

General

Brand	Allen-Bradley
Model	6181X-NPXPDC
Category	Desktop
Language	English
