Component Replacement Chapter 4
Install an Add-in Card
Follows these steps to install an add-in card.
1. Disconnect power from the computer.
2. Remove the back cover from the computer.
See Remove the Cover
instructions on page 37 for more information.
3. Remove the one screw that secures the slot cover.
Do not discard the screw.
4. Remove the slot cover and store it for reassembly later.
5. Hold the add-in card by its edge and remove it from its protective
packaging.
6. Connect the add-in card to the compatible riser-board slot.
Verify that the card is properly seated in the slot.
7. Secure the add-in card with the screw from the slot cover.
8. Connect the necessary cables to the add-in card.
See the documentation that came with the card.
9. Reinstall the rear cover.
See Reinstall the Cover
instructions on page 38 for more information.
When used in hazardous locations, the computer supports peripheral cards rated
4 W maximum, and Class I, Division 2, Groups A, B, C, D, T4. For ATEX and IECEx
applications, operation in Group IIC Category 3 gas and dust environments is
supported.
At maximum computer temperature, consider the following:
• A PCI card that dissipates 4 W can experience a surrounding air
temperature up to 90 °C (194 °F
).
• A PCI card that dissipates 1 W can experience a surrounding air
temperature up to 85 °C (185 °F
).
ATTENTION: Do not discard the slot cover. If the add-in card is removed
in the future, the slot cover must be reinstalled to maintain agency
access requirements.
