Rockwell Automation Publication 6181X-UM001C-EN-P - July 2015 39
Component Replacement Chapter 4
CompactFlash Card
The computers have two locations for loading CompactFlash (CF) Type II cards:
•
One solid-state drive bay is on the side of the computer. Cards that are
installed in this bay are bootable and function as the main drive.
•
One CF slot is on the I/O port panel below the serial ports. This slot is
functionally hot-swappable but only in a nonhazardous location. It is meant
to be a data slot but it is bootable.
See Hardware Features on page 14 for CF card slot locations.
Install a Card in the Solid-state Drive Bay
Follow these steps to load a CF card in the solid-state drive bay on the side of the
computer.
1. Follow the steps for Pre-configuration
on page 36.
2. Loosen the screw that secures the drive bay cover (A).
3. Loosen the screw that secures the drive bay lever (B).
4. Open the drive bay lever (C).
5. Pull out the CF card tray (D).
6. Remove the CF card lock screw (E).
WARNING: Do not connect or disconnect components unless power has
been switched off and the area is known to be nonhazardous.
WARNING:
Use only catalog numbers 6189V-CFSSD8GB and 6189V-CFSSD16GB
CF cards in the 6181X computers for hazardous locations.
Substitution of components can impair suitability for hazardous locations.
WARNING: The drive bay on the side of all computer models is not
hot-swappable. You must first shut down the computer before you can insert or
remove a CF card from this bay.
Do not connect or disconnect components unless power has been switched off and
the area is known to be nonhazardous.
