14 Rockwell Automation Publication 5069-UM003A-EN-P - May 2018
Chapter 2 Compact 5000 I/O Serial Module Operation in a Logix 5000 Control System
Local I/O or Remote
I/O Modules
You can use a Compact 5000 I/O Serial module as a local or remote I/O
module.
Local I/O Module
When Compact 5000 I/O Serial module resides in the same system as the
controller, it is a local I/O module. Local I/O modules are installed to the right
of the controller and exchange data with the controller over the system
backplane.
Figure 2 - Compact 5000 I/O Serial Module as Local I/O Module
IMPORTANT Compact 5000 I/O Serial modules can function as local I/O modules in the
following:
• CompactLogix 5380 control systems
• Compact GuardLogix 5380 control systems.
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
ANALOG INPUT
5069-IY4
ANALOG OUTPUT
5069-OF8
5069-SERIAL
CH0 TXD
CH0 RXD
CH1 TXD
CH1 RXD
SERIAL
MOD PowerSA Power
CompactLogix 5380 Controller
Local Compact 5000 I/O Standard Modules
