Chapter 4 Configure Compact 5000 I/O Serial Module
Edit the Module
Configuration
You click the category names in the New Module dialog box to view and
change the configuration parameters.
Some new module configuration categories apply to all Compact 5000 I/O
digital modules. Some categories are specific to the module type.
The following categories apply to all Compact 5000 I/O modules and are
described in this section.
• General Category
• Connection Category
• Module Info Category
• View the Module Tags
General Category
The General category appears first when you create a module. The parameters
in this category are the same for all Compact 5000 I/O modules.
You use this category to complete the following optional tasks:
• Name the module.
• Assign a slot number. (required)
• Describe the module.
• Access the Module Definition.
IMPORTANT This chapter shows how to edit configuration when you add the module to
the Logix Designer application project.
If you access the module configuration after it is added to the project, the
dialog box is named Module Properties. The same categories are displayed
as the categories displayed on the New Module dialog box.
