Allen-Bradley Compact 5000 User Manual

Rockwell Automation Publication 5069-UM003A-EN-P - May 2018 15
Compact 5000 I/O Serial Module Operation in a Logix 5000 Control System Chapter 2
Remote I/O Module
When a Compact 5000 I/O Serial module resides in a separate location from
the controller, it is a remote I/O module. Remote Compact 5000 I/O modules
are accessible over an EtherNet/IP network via a Compact 5000 I/O
EtherNet/IP adapter.
Remote Compact 5000 I/O modules are installed to the right of the adapter
and exchange data across the remote system backplane. The data is exchanged
with the controller over the EtherNet/IP network.
Figure 3 - Compact 5000 I/O Serial Module as Remote I/O Module
IMPORTANT Compact 5000 I/O Serial modules can function as remote I/O modules in the
following:
• CompactLogix 5380 control systems
• Compact GuardLogix 5380 control systems
• ControlLogix 5580 control systems
• GuardLogix 5580 control systems
527
F1
F2
F3
F4
F5
F6
F7
F8
F9
F10
F11
F12
F13
F14
F15
F16
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
ANALOG INPUT
5069-IY4
ANALOG OUTPUT
5069-OF8
5069-SERIAL
CH0 TXD
CH0 RXD
CH1 TXD
CH1 RXD
SERIAL
MOD PowerSA Power
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
ANALOG INPUT
5069-IY4
ANALOG OUTPUT
5069-OF8
5069-SERIAL
CH0 TXD
CH0 RXD
CH1 TXD
CH1 RXD
SERIAL
Compact 5000™ I/O
Compact 5000™ I/O
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
ANALOG INPUT
5069-IY4
ANALOG OUTPUT
5069-OF8
5069-SERIAL
CH0 TXD
CH0 RXD
CH1 TXD
CH1 RXD
SERIAL
Compact 5000™ I/O
PanelView™ Plus 7 Terminal
CompactLogix 5380 Controller
Compact 5000 I/O Digital Modules
Stratix 5400
Switch
Compact 5000 I/O EtherNet/IP Adapter
Compact 5000 I/O Digital Modules
PowerFlex
® 527 Drive
Compact 5000 I/O Modules
