158 Rockwell Automation Publication 2080-UM002G-EN-E - March 2015
Appendix A Specifications
Insulation stripping length 7 mm (0.28 in.)
Enclosure type rating Meets IP20
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
Inputs
Attribute High-Speed DC Input
(Inputs 0…3)
Standard DC Input
(inputs 4 and higher)
Number of Inputs 4 2
Input group to backplane isolation Verified by one of the following dielectric tests: 1,414V DC for 2 s
75V DC working voltage (IEC Class 2 reinforced insulation)
Voltage category 24V DC sink/source
Off-state voltage, max 5V DC
On-state voltage , nom 24V DC
On-state voltage range 16.8…26.4V DC @ 65 °C (149 °F)
16.8…30.0V DC @ 30 °C (86 °F)
10…26.4V DC @ 65 °C (149 °F)
10…30.0V DC @ 30 °C (86 °F)
Off-state current, max 1.5 mA
On-state current, min 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 8.8 mA @ 24V DC 8.5 mA @ 24V DC
On-state current, max 12.0 mA @ 30V DC
Nominal impedance 3 kΩ 3.74 kΩ
IEC input compatibility Type 3
AC input filter setting 8 ms for all embedded inputs
(In Connected Components Workbench, go to the Embedded I/O configuration window to reconfigure
the filter setting for each input group)
General – 2080-LC30-10QWB, 2080-LC30-10QVB
Attribute 2080-LC30-10QWB 2080-LC30-10QVB
Isolated AC Inputs (2080-LC30-10QWB, 2080-LC30-10QVB) (Inputs 0…3)
Attribute Value
On-state voltage, nom 12/24V AC @ 50/60 Hz
Off-state voltage, min 4V AC @ 50/60Hz
Operating frequency, nom 50/60 Hz
