Rockwell Automation Publication 2080-UM002G-EN-E - March 2015 157
Appendix
A
Specifications
Micro830 Controllers
Micro830 10-Point Controllers
Specifications for the analog and discrete Micro800 plug-in and
expansion I/O modules are available in the following
Rockwell Automation publications:
• Micro800 Discrete and Analog Expansion I/O User Manual,
publication 2080-UM003
• Micro800 Plug-in Modules User Manual, publication 2080-UM004
General – 2080-LC30-10QWB, 2080-LC30-10QVB
Attribute 2080-LC30-10QWB 2080-LC30-10QVB
Number of I/O 10 (6 inputs, 4 outputs)
Dimensions
HxWxD
90 x 100 x 80 mm
(3.54 x 3.94 x 3.15 in.)
Shipping weight, approx. 0.302 kg (0.666 lb)
Wire size 0.14…2.5 mm
2
(26…14 AWG) solid copper wire or
0.14…1.5 mm
2
(26…14 AWG) stranded copper wire
rated @ 90 °C (194 °F ) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type Use copper conductors only
Terminal screw torque 0.6 Nm (4.4 lb-in) max
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
Input circuit type 12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay 24V DC sink transistor (standard and high-speed)
Event input interrupt support Yes
Power consumption 7.88 W
Power supply voltage range 20.4…26.4V DC Class 2
I/O rating Input 24V DC, 8.8 mA
Output 2 A, 240V AC, general use
Input 24V DC, 8.8 mA
Output 2 A, 24V DC, 1 A per point (Surrounding air
temperature 30 °C)
24 V DC, 0.3 A per point (Surrounding air temperature
65 °C)
Isolation voltage 250V (continuous), Reinforced Insulation Type, Outputs to
Aux and Network, Inputs to Outputs
Type tested for 60 s @ 720 V DC, Inputs to Aux and Network,
3250 V DC Outputs to Aux and Network, Inputs to Outputs
50V (continuous), Reinforced Insulation Type, I/O to Aux
and Network, Inputs to Outputs
Type tested for 60 s @ 720 V DC, I/O to Aux and Network,
Inputs to Outputs
Pilot duty rating C300, R150 —
