Allen-Bradley Micro830

168 Rockwell Automation Publication 2080-UM002G-EN-E - March 2015
Appendix A Specifications
Micro830 48-Point Controllers
Certifications
Certification (when
product is marked)
(1)
Value
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See
UL File E322657.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations,
certified for U.S. and Canada. See UL File E334470.
CE European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2006/95/EC LVD, compliant with:
EN 61131-2; Programmable Controllers (Clause 11)
C-Tick Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
(1) See the Product Certification link at http://www.rockwellautomation.com/products/certification/ for
Declaration of Conformity, Certificates, and other certification details.
General Specifications – 2080-LC30-48AWB, 2080-LC30-48QWB, 2080-LC30-48QVB, 2080-LC30-48QBB
Attribute 2080-LC30-48AWB 2080-LC30-48QWB 2080-LC30-48QVB 2080-LC30-48QBB
Number of I/O 48 (28 inputs, 20 outputs)
Dimensions
HxWxD
90 x 230 x 80 mm
(3.54 x 9.06 x 3.15 in.)
Shipping weight,
approx.
0.725 kg (1.60 lb)
Wire size 0.2…2.5 mm
2
(24…12 AWG) solid copper wire or
0.2…2.5 mm
2
(24…12 AWG) stranded copper wire
rated @ 90 °C (194 °F ) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type Use copper conductors only
Terminal screw
torque
0.6 Nm (4.4 lb-in) max
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
Input circuit type 120V AC 12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay 24V DC sink (standard and
high-speed)
24V DC source (standard and
high-speed)
Event input interrupt
support
Yes, inputs 0…15 only
Power consumption 18.2 W
Power supply
voltage range
20.4…26.4V DC Class 2
