Allen-Bradley Micro830 User Manual

Rockwell Automation Publication 2080-UM002G-EN-E - March 2015 169
Specifications Appendix A
I/O rating Input 120V AC, 16 mA
Output 2 A, 240V AC,
general use
Input 24V DC, 8.8 mA
Output 2 A, 240V AC,
general use
Input 24V DC, 8.8 mA
Output 24V DC, 1 A per point (Surrounding air temperature
30 °C)
24 V DC, 0.3 A per point (Surrounding air temperature 65 °C)
Insulation stripping
length
7 mm (0.28 in.)
Enclosure type
rating
Meets IP20
Pilot duty rating C300, R150 —
Isolation voltage 250V (continuous), Reinforced
Insulation Type, Outputs to Aux
and Network, Inputs to Outputs
Type tested for 60 s @
3250V DC I/O to Aux and
Network, Inputs to Outputs
250V (continuous),
Reinforced Insulation Type,
Outputs to Aux and Network,
Inputs to Outputs
Type tested for 60 s @
720V DC, Inputs to Aux and
Network, 3250V DC Outputs
to Aux and Network, Inputs
to Outputs
50V (continuous), Reinforced Insulation Type, I/O to Aux and
Network, Inputs to Outputs
Type tested for 60 s @ 720V DC, I/O to Aux and Network, Inputs
to Outputs
North American
temp code
T4
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
Inputs
Attribute 2080-LC30-48AWB 2080-LC30-48QWB / 2080-LC30-48QVB / 2080-LC30-48QBB
120V AC Input High-Speed DC Input
(Inputs 0…11)
Standard DC Input
(Inputs 12 and higher)
Number of Inputs 28 12 16
Voltage category 110V AC 24V DC sink/source
Operating voltage 132V, 60Hz AC, max 16.8…26.4V DC 10…26.4V DC
Off-state voltage, max 20V AC 5V DC
Off-state current, max 1.5 mA 1.5 mA
On-state current, min 5 mA @ 79V AC 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 12 mA @ 120V AC 8.8 mA @ 24V DC 8.5 mA @ 24V DC
On-state current, max 16 mA @ 132V AC 12.0 mA @ 30V DC
Nominal impedance 12 kΩ @ 50 Hz
10 kΩ @ 60 Hz
3 kΩ 3.74 kΩ
IEC input compatibility Type 3
Inrush current, max 250 mA @ 120V AC
Input frequency, max 63 Hz
AC input filter setting 8 ms for all embedded inputs
(In Connected Components Workbench, go to the Embedded I/O configuration window to reconfigure the filter setting
for each input group)
General Specifications – 2080-LC30-48AWB, 2080-LC30-48QWB, 2080-LC30-48QVB, 2080-LC30-48QBB
Attribute 2080-LC30-48AWB 2080-LC30-48QWB 2080-LC30-48QVB 2080-LC30-48QBB
