178 Rockwell Automation Publication 2080-UM002G-EN-E - March 2015
Appendix A Specifications
Power consumption 33 W
Power supply voltage range 20.4…26.4V DC Class 2
I/O rating Input 120V AC, 16 mA
Output 2 A, 240V AC,
2A, 24V DC
Input 24V, 8.8 mA
Output 2 A, 240V AC, 2 A,
24V DC
Input 24V, 8.8 mA
Output 24V DC, 1 A per point (surrounding air
temperature 30 °C)
24V DC, 0.3 A per point (surrounding air temperature
65 °C)
Insulation stripping length 7 mm (0.28 in)
Enclosure type rating Meets IP20
Pilot duty rating C300, R150 –
Isolation voltage 250V (continuous), Reinforced
Insulation Type, Output to Aux
and Network, Inputs to
Outputs.
Type tested for 60 s @ 3250V
DC Output to Aux and
Network, Inputs to Outputs.
150V (continuous), Reinforced
Insulation Type, Input to Aux
and Network
Type tested for 60 s @ 1950V
DC Input to Aux and Network.
250V (continuous), Reinforced
Insulation Type, Output to Aux
and Network, Inputs to Outputs
Type tested for 60 s @ 3250V DC
Output to Aux and Network,
Inputs to Outputs
50V (continuous), Reinforced
Insulation Type, Input to Aux and
Network
Type tested for 60 s @ 720V DC,
Inputs to Aux and Network
50V (continuous), Reinforced Insulation Type, I/O to
Aux and Network, Inputs to Outputs
Type tested for 60 s @ 720V DC, I/O to Aux and
Network, Inputs to Outputs.
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
Input Specifications
Attribute 2080-LC50-48AWB 2080-LC50-48QWB / 2080-LC50-48QVB / 2080-LC50-48QBB
120V AC Input High-Speed DC Input
(Inputs 0…11)
Standard DC Input
(Inputs 12 and higher)
Number of Inputs 28 12 16
Input group to backplane
isolation
Verified by the following dielectric
tests: 1950V AC for 2 s
150V working voltage (IEC Class 2
reinforced insulation)
Verified by the following dielectric tests: 720V DC for 2 s
50V DC working voltage (IEC Class 2 reinforced insulation)
Voltage category 110V AC 24V DC sink/source
Operating voltage range 132V, 60Hz AC max 16.8…26.4V DC @ 65°C (149°F)
16.8…30.0V DC @ 30°C (86°F)
10…26.4V DC @ 65°C (149°F)
10…30.0V DC @ 30°C (86°F)
Off-state voltage, max 20V AC 5V DC
Off-state current, max 1.5 mA 1.5 mA
On-state current, min 5 mA @ 79V AC 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 12 mA @ 120V AC 7.6 mA @ 24V DC 6.15 mA @ 24V DC
On-state current, max 16 mA @ 132V AC 12.0 mA @ 30V DC
Nominal impedance 12 kΩ @ 50 Hz
10 kΩ @ 60 Hz
3 kΩ 3.74 kΩ
IEC input compatibility Type 3
Inrush current, max 250 mA @ 120V AC –
Input frequency, max 63 Hz –
General Specifications – 2080-LC50-48AWB, 2080-LC50-48QWB, 2080-LC50-48QVB, 2080-LC50-48QBB
Attribute 2080-LC50-48AWB 2080-LC50-48QWB 2080-LC50-48QVB 2080-LC50-48QBB
